Experimental contents
☆To observe nuclear magnetic resonance phenomenon of hydrogen nucleus in liquid samples and fluorine nucleus in solid samples.
☆To calculate g factors in hydrogen nucleus and fluorine nucleus.
Features
☆Adjustable uniform magnetic field.
☆Two-dimensional adjustable probe.
☆Replaceable probe samples.
☆Clear resonance signal.
Configuration and technical parameters
☆U type field coil, 5A and 1000 turns, with field sweep coil, 1A, 220 turns
☆Adjustable DC (constant current) power supply, 3.5A/6.3V;
☆Guide rail length 300mm; adjustable range of lifting adjusting bracket.
